High Quality Welding Machine
High Quality Welding Machine
Products Description
High Quality Welding Machine can carry out long-distance, large workpiece laser welding, and the welding heat-affected area is small, which will not lead to workpiece deformation, blackening, back traces of the problem, and welding depth, solid welding, dissolution is sufficient, dissolution pool dissolution material raised part of the combination with the substrate without depression phenomenon.
product Features
| 1. The laser beam quality is good, the welding speed is fast, the welding seam is firm and beautiful, and it brings users an efficient and perfect welding solution. |
| 2. Hand-held water-cooled welding gun, ergonomic design, flexible and convenient, longer welding distance, and can weld the workpiece at any angle. |
| 3. The welding area has little heat influence, is not easy to be deformed, blackened, and has traces on the back. The welding depth is large, the melting is sufficient, and it is firm and reliable. |
| 4. Higher electro-optical conversion efficiency , lower energy consumption, and the operation is simple and easy to learn. There is no need for a professional welding master. Ordinary workers can start after a short training. Long-term use can greatly save processing costs. |
| 5. High safety, the welding tip is only effective when the switch is touched when it touches the metal, and the touch switch has body temperature sensor. |
| 6. It can realize welding at any angle, and can weld various complex welded workpieces and large workpieces with irregular shapes. Realize welding at any angle. |
Main Parameters And Configurations
| Model | DS-LW1000/DS-LW1500/DS-LW2000/DS-LW3000 |
| Laser Power | 1000W/1500W/2000W/3000W |
| Wavelength | 1080nm |
| Welding penetration | 0.5~5mm |
| Spot size | 0.2~1.8mm |
| Welding material | carbon steel, stainless steel,galvanized sheet,aluminum,copper,brass,aluminum alloy,iron.. |
| Laser source | MAX/Raycus/JPT/IPG |
| Optical fiber cable | 10 meter |
| Total powe | 5KW |
| Power supply | 220V/380V, 50/60HZ |
Workshop Of Dotslaser
Daily maintenance
● After finishing work, make sure the floor is clean. Then clean the machine including the surface of the machine, the case of the optical system, the surface of the monitor, the work table, and so on.
● Please turn off each part and main power supply when they are clean.
● Check the lens regularly for dust. When it's clean, use the cotton wool with greater than 95% medical grade alcohol to wipe clockwise from the center of the lens. When you need to move the machine to avoid bumps. Check the connection cable according to the cable list.
