Products Description
CO2 Engraver is a state-of-the-art laser engraving machine that is designed to deliver highly accurate and precise marking on a wide range of materials. With its advanced technology, the engraver is capable of delivering detailed and intricate designs on any surface with utmost accuracy and consistency.
About the Galvo Laser Engraver...
The engraver features a high-speed galvanometer system that enables it to deliver high-speed and high-precision marking with exceptional stability.Its galvanometer system has a speed of up to 7000mm/s, which allows for quick and efficient marking processes.
This laser engraving machine is equipped with a powerful laser source. With its 30W~350W laser source, the Galvo Laser Engraver also features an air cooling mechanism that keeps the laser source cool.
The Galvo Laser Engraver comes with simple software that allows users to design and input their desired marking patterns with ease. The software is user-friendly, making it easy for users to make changes to the designs, change fonts, adjust sizes, and add special effects to their markings.
The Galvo Laser Engraver also has a low maintenance cost, making it an economical solution for businesses that need to mark their products consistently over long periods.
Galvo Laser Engraver Features:
| Marking faster and Precise. | ||||
| Flexible configurations for various applications. | ||||
| Rotary and shuttle tables produce more productivity. | ||||
| CO2 Engraverare designed for marking, engraving, cutting, and organic materials such as wood, stone, ceramic, fabric, heavy powder-coated objects, and paper. These systems have a diverse set of abilities, making them ideal for integrating with industrial applications where marking and engraving are part of a larger assembly process. | ||||
| CO2 Engravers are inherently fast. They are known for their speed and precision when marking drinkware due to their ability to mark on the curved irregular surface without rotation of the object. |
Paramters of Galvo Laser Engraver
|
NO. |
Name |
DS-LMC series Galvo laser system |
|
1 |
Machine model |
DS-LMC250/DS-LMC350 |
|
2 |
Max laser power |
250W/350W |
|
3 |
Laser wavelength |
10.6μm |
|
4 |
Beam quality |
＜1.2㎡ |
|
5 |
Duty cycle limit |
≤60% |
|
6 |
Min.line width |
0.22mm(depend on the material) |
|
7 |
Min.character size |
0.4mm |
|
8 |
Max marking speed |
≤8,000mm/s |
|
9 |
Working area |
1200x1200mm |
|
10 |
Cooling |
Water cooled |
|
11 |
Working environment temperature range |
5~35 ℃ |
|
12 |
Humidity range of working environment |
< 70% No condensation |
|
13 |
Power supply |
220V,50/60Hz |
|
14 |
Power consumption |
＜6KW |
How Does a Galvanometer System Work in a Laser Engraver?
1. When you ensure start to engrave the project, the computer sends coordinates to the galvanometer system about where and how the laser beam needs to be directed. The galvanometers then will control the mirrors to adjust the beam's location and angle, this is convenient to determines the engraving shape, depth, and detail.
2. A closed-loop control mechanism attaches to the galvanometer system using, which means that the system continually monitors the position of the mirrors and readjusts them in real-time to maintain accuracy and precision. This mechanism ensures that the laser beam accurately follows the intended path and provides sharp, clear engravings.
1. Speed: Gavo laser engravers use a scanning system and a high-speed galvanometer, so they don't require any movement of the laser diode. This allows for much faster engraving speeds compared to XY axis engravers. XY axis engravers may be slower than Gavo laser engravers since their process requires more mechanical movement.
2. Flexibility: Complex, curved, or irregularly shaped objects is more suitable for galvo laser engravers, since the laser beam can be quickly and easily adjusted to follow the contours of the material. By contrast, conventional XY axis laser engravers are typically better-suited for engraving flat surfaces or materials that can be affixed to a flat worktable.
3 Productivity: Galvo Laser engravers is more precious and detail in engraving applications. However, since the scanning system allows for finer control over the position and movement of the laser beam. This can be particularly important for applications that require very small or intricate engravings.
4. Use of lens: Machine uses F-theta lens, it directly reduces error and operational losses.Traditional lasers do not uses F-theta lens which is why it cannot become faster like the galvo.
Samples show
Packaging and shipping
Certifications
