Wood Laser Marking Machine
Wood Laser Marking Machine
Products Description
Wood laser marker is a laser system specifically designed for engraving, cutting, or marking various types of wood. These machines utilize laser beams to create precise and intricate designs on wooden surfaces with high accuracy, resolution, and speed. Wood laser marking machines typically use CO2 lasers, which have a wavelength of around 10.6 micrometers. This wavelength is ideal for working with organic materials like wood, as their energy is well absorbed in a process called material ablation (removal of material through vaporization).
Advantages of using a wood laser marker
Precise marking: Laser marking machines offer high-resolution, detailed engraving and marking effect on wood surfaces, making them suitable for creating intricate designs and patterns.
Multifunctio: These machines can work with various wood types, such as hardwoods, softwoods, veneers, plywood, MDF, and other composite materials. Additionally, they can be used for applications like cutting, inlay work, or marquetry.
Efficiency: Wood laser marking machines can quickly create marks, reducing production time and increasing overall productivity.
Non-contact: The non-contact nature of laser marking machines prevents mechanical stress and damage to the wood, ensuring that delicate and fragile pieces remain intact during the marking process.
High-quality marks: The laser marking process produces clean, sharp, and highly detailed marks that are resistant to fading and wear over time.
Applicable material:
DOTSLASER wood lasrer marking machine is suitable for laser engraving, laser cutting, laser marking, laser drilling and other processes on various non-metallic materials, such as leather, cloth, paper, PVC, rubber, wood, plastic and other surfaces.
Basic configuration
|
Model |
DS-LMC30 |
DS-LMC60 |
|
Laser power output |
>30W |
>60W |
|
Laser wavelength |
10640±10 nm |
|
|
Aperture of scan head |
20mm |
|
|
Marking area |
100x100mm(standard)/175x175mm/200x200mm/300x300mm |
|
|
Pulse frequency |
1~100KHZ |
|
|
Max marking speed |
8000mm/s |
|
|
Repeat accuracy |
±0.001mm |
|
|
Min.line width |
0.1mm |
|
|
Min.character size |
0.2mm |
|
|
Cooling |
Air cooled |
|
|
Working temperature |
5~35 ℃ |
|
|
Humidity range |
< 70% No condensation |
|
|
Gross weight |
65KG |
|
|
Power supply |
AC220V±10%,50Hz or AC110V±10%,60Hz |
|
When choosing a wood engraver, consider these important factors:
Power: Ensure that the laser power is sufficient for your desired application, as higher-powered lasers can cut through thicker materials and work at faster speeds.
Working area: Make sure the size of the working area meets your production needs.
Compatibility: Ensure that the machine's software is compatible with your preferred design applications (e.g., CorelDRAW, Illustrator, AutoCAD, etc.).
User-friendliness: Check for user-friendly features such as intuitive interfaces, adjustable settings, and accessible maintenance components.
Cooling system: Verify if the machine has an adequate cooling system to maintain stable operation during extended periods of use.
By considering these factors, you can select the best wood laser marking machine to suit your specific requirements and enjoy the efficiency and high-quality output that wood laser marking machines have to offer.
Product performances and features
1. Completely sealed maintenance-free laser optical system, hassle-free and ready for immediate use.
2. Top-quality RF laser tube with high power output, excellent spot quality, consistent power delivery, and an impressive lifespan exceeding 20,000 hours.
3. With exceptional precision and rapid marking/cutting capabilities, this system boosts productivity by 20% compared to comparable models.
4. The advanced constant temperature circulating industrial cooling water system ensures the smooth operation of the machine and reduces power consumption significantly.
5. Stringent multiple protection measures have been implemented in the design of our laser marking system, making it ideal for operation in diverse ambient temperatures. This ensures the system's constant and dependable performance 24/7.
6. The application system within the Windows interface seamlessly integrates with popular software programs like AutoCAD, CorelDraw, and Photoshop, supporting file formats such as PLT, DXF, BMP, and more.
The wood laser engraving machine utilizes cutting-edge 3D dynamic marking technology, allowing it to effortlessly engrave surfaces with varying heights by adjusting settings in the software. With a remarkable processing speed of up to 8,000mm/s, this machine is perfect for streamlining industrial mass production.
Furthermore, the equipment is equipped with a fully enclosed optical path, utilizing a high-quality CO2 radio frequency laser imported from reputed suppliers.
Samples show
Benefits of choosing our products
Wood laser marker adopted imported or Chinese top brand CO2 RF metal tube and high-speed galvanometer head are used. The whole system has high marking accuracy, fast speed, extremely stable performance, can work continuously for a long time, and can be directly applied to large-scale online processing production lines. Wood laser marking machines have been widely used in food, beverage, wood, leather, glass and other packaging industries.
Used to mark the production date, batch number, serial number, etc. of the product. It is easy to use and has low operating cost. The product is installed on an automatic assembly line and adopts fully automatic operation and computer panel control. A permanent mark can be formed, and the serial number can be used to identify a single product that cannot be changed, which can eliminate the possibility of counterfeiting and shoddy after cleaning with waste packaging.
